Description
Print Method – Serial Impact Dot Matrix
Print Direction – Bi directional Logic seeking
Print Head – Type 9 Wire
Print Width – 80 Column
Print Head Life – 200 million characters
Print Speed
- Character Pitch cpi – 10 12 15
- High Speed Draft cps – 333 – 338
- Draft cps – 300 250
- Near letter quality cps – 300 360 450
Resident Printer Fonts
- High Speed Draft – 380 – 450
- Draft – Standard 10, 12, 15, 17 and 20 cpi
- Near Letter Quality – Roman, Sans Serif, Script
- Resident bar code – Code 3 of 9
- Paper path standard – Top, Rear and Bottom
- Continuous Tractor feed standard – Convertible push & Pull
- Continuous form width – 3.5 – 10 “
- Cut sheets width – 3.5 – 10 “
- Paper thickness max – Tractor feed 0.3mm / Friction feed 0.3mm
- Copy capability – 1 + 4
- Type – Patented TVS ribbon cassette with user
- Colour – Jet black
- Ribbon Life – 40 Million characters with 3 additional inkbanks
- Cassette refill mode – Through Inkbank
- Inkbank life – 10 Million Characters
- Input Buffer Kilo bytes – 100 KB
- Reliability MTBF Power on Hours – 15,000 POH
- Acoustics Noise level – 55 dBA ISO standard
- Emulation – ESC/P
- Standard Interface – Centeronics IEEE/P1284A Parallel , USB 2.0
- Optional Interface – RS 232C Serial
- Operating voltage – 150 – 270V AC
- Mains frequency – 47 – 63 Hz
- Power Standby – 12W
- Temperature – +5 to + 45ºC
- Relative Humidity – 10% to 80%
- Size W x D x Hmm – 433 x 379 x 147
- Weight – 5.7 kg
- Warranty – 2 Years incl. Print head (only valid on registration)
- Best Suited for Printing – Bills | Receipts | Tickets | Coupons | Invoices | Statements 1 kg = 2.2lbs, 1 inch = 2.54 cms *Max. possible copy capability **@ Draft 10 cpi #@ 33% print density and 25% duty cycle Excluding print head @ 33% print density and 25% duty cycle #.
